Contents

{:.no_toc}

• Will be replaced with the ToC, excluding the “Contents” header {:toc}

Introduction

Examples shows explicit examples for different syntaxes. Other Syntaxes show the syntaxes that can’t be shown explicitly.

Organization

• Header levels (except possibly the last header level): features in groups
• Last header level or a list: different syntaxes
• TaskPaper-styled tags to indicate in what favor of Markdown such syntax is supported
  • @markdown: supported by original markdown, hence understood to be supported by all variants of markdown
  • @ghpages: GitHub-Favored Markdown, built by kramdown with GFM option. i.e. GitHub Pages’ GitHub-Favored Markdown
  • @mmd: MultiMarkdown
  • @pandoc: pandoc-favored markdown
  • @phpextra: PHP Markdown Extra (inspired some syntax in pandoc and mmd and gfm, not exhaustively tested here)
• TaskPaper Tags
  • @...(partial): partial supports only
  • @...(+...): when the extension is used
  • @pandoc(--...): when the command line argument is used
  • @pandoc(parsed): not verbatim, but parsed

Note:

• You might see <!-- \begin{comment} -->...<!-- \end{comment} -->. This is for mmd to tex to pdf use only. Ignore this.

Examples

Header

@markdown

See Emphasis and Other Syntaxes to see alternative Setext-style header styles @markdown

Header Containing Styling and a Link

@markdown

Header Containing Attributes {#identifier .class1 key=value1}

@pandoc @phpextra

Header Unnumbered {-}

@pandoc

Header Unnumbered 2 {.Unnumbered}

@pandoc

Auto Cross Reference

• Link to Header @pandoc @ghpages @mmd
• Link to Header @pandoc @mmd
• Header @mmd @pandoc
• Header @mmd @pandoc

User defined reference

• userdefinedreference @mmd
• Link to userdefinedreference @mmd @pandoc(+mmd_header_identifiers)
• Link to “Header Containing Attributes” @pandoc
• another-link @pandoc

Deeper Levels of Headers

Header4

Header5

Header6

Backslash Escapes

*testing* @markdown

Emphasis

• italic or italic @markdown
• bold or bold @markdown
• bold italic or bold italic @markdown
• ~~strikethrough~~ @pandoc
• Small caps @pandoc @markdown(html)

CriticMarkup

Visually it looks like emphasis. Functionally it is much more, and called Critic Markup @mmd

• Deletions from the original text: This is {–is –}a test.
• Additions: This {++is ++}a test.
• Substitutions: This {~~isn’t_>is} a test.
• Highlighting: This is a {==test==}.
• Comments: This is a test{>>What is it a test of?<<}.

See more at CriticMarkup—MultiMarkdown Documentation.

Horizontal Rules

@markdown

3 or more hyphens or asterisks

Break

@markdown

No break like this

Soft break
like this

Hard break

like this

Superscript & Subscript

• x² @mmd
• d_o @mmd
• x^a+b @mmd @pandoc
• x_y,z @mmd @pandoc
• P_a\ cat~ @pandoc

Smarty Pants

@markdown(+smartypants) @pandoc(–smart) @ghpages

• “Example 1”
• ‘Example 2’
• en–dash
• em—dash
• ellipsis…

@mmd

• “Example 3”

Abbreviations (PHP Markdown Extra)

@mmd @phpextra @pandoc(+abbreviations)

Testing abbreviations: HTML, W3C (mouseover it to see)

Lists

Ordered Lists

@markdown

1. test
2. test
3. test

Unordered Lists

@markdown

• test
• test
• test

Nested Lists

@markdown

• test
  • test
• test
  1. test
  2. test
     • test
       1. test
       2. test
  3. test
• test

Note about LaTeX output in mmd/pandoc:

• The Maximum nesting level of lists in LaTeX is 4. The quick hack is to mix itemize and enumerate alternatively to go beyond this.

Cutoff a List

@markdown

1. one
2. two
3. three

1. uno
2. dos
3. tres

• item one
• item two

{ my code block }

List Item in a Block

@markdown

• First paragraph.

  Continued.

• Second paragraph. With a code block, which must be indented eight spaces:

  { code }


Fancy Lists

@pandoc

. one

. two

9) Ninth 10) Tenth 11) Eleventh i. i ii. ii iii. iii (2) Two (5) Three 1. Four * Five

Definition Lists

Method 1

@mmd @phpextra @pandoc @ghpages

Physics

The Fundamental of Science

Describe the Nature

Make Prediction

Method 2

@ghpages @pandoc @mmd

Term 1

Definition 1

Term 2 with inline markup

Definition 2

{ some code, part of Definition 2 }

Third paragraph of definition 2.

Numbered Example Lists

@pandoc

(@) My first example will be numbered (1). (@) My second example will be numbered (2).

Explanation of examples.

(@) My third example will be numbered (3).

(@good) This is a good example.

As (@good) illustrates, …

Code

• testing @markdown
• \[\ket{a}\]{.latex} @pandoc

Fenced Code Blocks

Method 1

@markdown

test
test
    test
    # test

Method 2

@markdown(partial:language-not-supported) @ghpages @pandoc @mmd

\nabla \times \mathbf{E} = - \frac{\partial \mathbf{B}}{\partial t}

Method 3

@pandoc

~~~markdown test test test # test ~~~

~~~ {#mycode .markdown .numberLines startFrom=“100”} test test test # test ~~~

Block-quotes

@markdown

Test

test

test

test

• test

• test

Block-quotes Quoting Codes

@markdown

\newcommand...

Line Blocks

@ghpages(partial) @pandoc

| The limerick packs laughs anatomical | In space that is quite economical. | But the good ones I’ve seen | So seldom are clean | And the clean ones so seldom are comical

| 200 Main St. | Berkeley, CA 94718

Tables

Method 1

@ghpages @pandoc @mmd

| Right | Left | Default | Center |

|——:|:—–|———|:——:|

| 12 | 12 | 12 | 12 |

| 123 | 123 | 123 | 123 |

| 1 | 1 | 1 | 1 |

Notice how pandoc can have optional caption like this

Method 2

@mmd

Method 3

@pandoc

Right Left Center Default ——- —— ———- ——- 12 12 12 12 123 123 123 123 1 1 1 1

Table: Demonstration of simple table syntax.

Method 4

@pandoc

Centered Default Right Left Header Aligned Aligned Aligned ———– ——- ————— ————————- First row 12.0 Example of a row that spans multiple lines.

Second row 5.0 Here’s another one. Note the blank line between

                                rows.

Table: Here’s the caption. It, too, may span multiple lines.

Method 5

@pandoc

Sample grid table.

+—————+—————+——————–+ | Fruit | Price | Advantages | +===============+===============+====================+ | Bananas | $1.34 | - built-in wrapper | | | | - bright color | +—————+—————+——————–+ | Oranges | $2.10 | - cures scurvy | | | | - tasty | +—————+—————+——————–+

Method 6

@ghpages

See Syntax | kramdown

Links

• https://www.wikipedia.org @pandoc(+autolink_bare_uris)
• https://www.wikipedia.org @markdown
• Wikipedia.org @markdown
• Wikipedia.org @markdown
• Mail to GitHub @markdown

Reference Links

• Search here @markdown
• A link with attributes. @mmd
• Another link to the link above. @mmd
• A link1 with attributes. @markdown
• Another link. @markdown
• link3. @markdown

Footnotes

• Footnotes [1] @mmd
• Footnotes ^[This is a pandoc inline footnote] @pandoc

Reference Footnotes

• Footnotes[2] @markdown
• Long Footnotes [3] @pandoc @ghpages @mmd

This paragraph won’t be part of the note, because it isn’t indented.

Glossaries

A special kind of footnote [4]. @mmd

See more at Glossary—MultiMarkdown Documentation.

Citations

It can looks like footnotes in HTML output.

MultiMarkdown

@mmd

• This is a statement that should be attributed to its source [p. 23, 5]Doe:2006.

notcited

See more at Citations—MultiMarkdown Documentation.

Pandoc

@pandoc

Very powerful but complicated. See more at Citations—Pandoc Documentation.

Images

• @markdown

Reference Images

• @markdown
• @mmd @pandoc(+mmd_link_attributes)
• {#id .class width=30 height=20px} @pandoc @phpextra(partial)
• a reference ![image][ref] with attributes. @pandoc @phpextra(partial)

[ref]: image.png “optional title” {#id .class key=val key2=“val 2”}

Image with Links by Nesting Image and Link

• @markdown

Block Level Images

• Block level: HTML figure element in MultiMarkdown @mmd @pandoc

RAW

HTML

• This should not be markdown (or is it?)
  @markdown
• This is markdown
  @mmd @pandoc(+markdown_attribute)

See more at Raw—MultiMarkdown Documentation. See test in [Babelmark 2 - Compare markdown implementations](http://johnmacfarlane.net/babelmark2/?normalize=1&text=%3Cdiv%3EThis+should+not+be+markdown+(or+is+it%3F%29+%3C%2Fdiv%3E%0A%3Cdiv+markdown%3D1%3EThis+is+markdown%3C%2Fdiv%3E).

LaTeX

• @mmd
• \newcommand\rawlatex{} @pandoc(parsed)
• \begin{…} @pandoc

Other Syntaxes

Metadata

Note: mmd accepts capitalized metadata keys but others do not. For maximum compatibility, author(s), title, etc. should be in lower cases.

MultiMarkdown Metadata Block

@mmd @pandoc(+mmd_title_block)

title:    A Sample MultiMarkdown Document
author:   Fletcher T. Penney
date:     February 9, 2011
comment:  This is a comment intended to demonstrate
          metadata that spans multiple lines, yet
          is treated as a single value.
CSS:      http://example.com/standard.css

See more at Metadata—MultiMarkdown Documentation.

Pandoc Title Block

@pandoc

% title
% author(s) (separated by semicolons)
% date

YAML Metadata Block

@Mmd(partial)

@pandoc @ghpages

---
title:    A Sample MultiMarkdown Document
author:   Fletcher T. Penney
date:     February 9, 2011
tags: [nothing, nothingness]
abstract: |
  This is the abstract.

  It consists of two paragraphs.
---

TOC

Pandoc

@pandoc

Use --toc as a command argument.

MultiMarkdown

@mmd

{{TOC}}, see beginning. It preprocess the headings and generate a ToC on its own, and doesn’t give instruction for LaTeX to generate one. A hack is like this:

---
...
LaTeX Input:    mmd-load-toc-setcounter
LaTeX Input:    mmd-load-toc
...
---
<!-- \begin{comment} -->
{{TOC}}
<!-- \end{comment} -->
...

See more at ickc/peg-multimarkdown-latex-support: Default support files for generating LaTeX documents with MMD 3 through MMD 5.

Kramdown

@ghpages

# Contents
{:.no_toc}

* Will be replaced with the ToC, excluding the "Contents" header
{:toc}

Math

MathJax is assumed. MathJax has many configurable options. See MathJax TeX and LaTeX Support — MathJax 2.6 documentation.

Markdown

@markdown

Add the following at the beginning of the document:

<script type="text/javascript"
    src="https://cdn.mathjax.org/mathjax/latest/MathJax.js?config=TeX-AMS_CHTML-full">
    </script>

MathJax.js is used and any codes within math delimiters are treated as raw HTML and to be processed by MathJax.

MathJax delimiter are $$...$$, \\(...\\) and \\[...\\] (because an extra \ can be used to escape from MarkDown).

Depending on the markdown parser, extra tricks might be needed to make sure nothing within the math delimiter is treated as markdown (see TeX and LaTeX in HTML documents — MathJax 2.6 documentation). $...$ can be used with MathJax configuration (see TeX and LaTeX math delimiters — MathJax 2.6 documentation).

MultiMarkdown and Pandoc

There are subtleties how math should be used in HTML+MathJax and LaTeX output from single markdown source. See more in Testing LaTeX Environments Usage in MathJax From Markdown Conversion (including mmd and pandoc).

MultiMarkdown

@mmd

Add the following metadata at the beginning of the document:

HTML header:    <script type="text/javascript"
    src="https://cdn.mathjax.org/mathjax/latest/MathJax.js?config=TeX-AMS_CHTML-full">
    </script>

MultiMarkdown math delimiter are $...$, $$...$$, \\(...\\) and \\[...\\].

Pandoc

@pandoc(–mathjax)

For pandoc, add --mathjax in the command-line argument.

Default math delimiter for pandoc is $...$, $$...$$. Other options are configurable. See more in Pandoc - Pandoc User’s Guide.

Inline Math

• \(1+1\)
• \(1 + 1\) @pandoc(+tex_math_double_backslash)

Block Math

• \[R R^T = I\]
• \[A^T_S = B\]

Other Examples

• \[x = {-b \pm \sqrt{b^2-4ac} \over 2a}\]
• $$ \begin{aligned} \dot{x} & = \sigma(y-x) \ \dot{y} & = \rho x - y - xz \ \dot{z} & = -\beta z + xy \end{aligned} $$
• \[\left( \sum_{k=1}^n a_k b_k \right)^2 \leq \left( \sum_{k=1}^n a_k^2 \right) \left( \sum_{k=1}^n b_k^2 \right)\]
• \[\mathbf{V}_1 \times \mathbf{V}_2 = \begin{vmatrix} \mathbf{i} & \mathbf{j} & \mathbf{k} \\\ \frac{\partial X}{\partial u} & \frac{\partial Y}{\partial u} & 0 \\\ \frac{\partial X}{\partial v} & \frac{\partial Y}{\partial v} & 0 \end{vmatrix}\]
• \[P(E) = {n \choose k} p^k (1-p)^{n-k}\]
• \[\frac{1}{\Bigl(\sqrt{\phi \sqrt{5}}-\phi\Bigr) e^{\frac25 \pi}} = 1+\frac{e^{-2\pi}} {1+\frac{e^{-4\pi}} {1+\frac{e^{-6\pi}} {1+\frac{e^{-8\pi}} {1+\ldots} } } }\]
• $$ \begin{aligned} \nabla \times \vec{\mathbf{B}} -\, \frac1c\, \frac{\partial\vec{\mathbf{E}}}{\partial t} & = \frac{4\pi}{c}\vec{\mathbf{j}} \ \nabla \cdot \vec{\mathbf{E}} & = 4 \pi \rho \ \nabla \times \vec{\mathbf{E}}\, +\, \frac1c\, \frac{\partial\vec{\mathbf{B}}}{\partial t} & = \vec{\mathbf{0}} \ \nabla \cdot \vec{\mathbf{B}} & = 0 \end{aligned} $$
• \[1 + \frac{q^2}{(1-q)}+\frac{q^6}{(1-q)(1-q^2)}+\cdots = \prod_{j=0}^{\infty}\frac{1}{(1-q^{5j+2})(1-q^{5j+3})}, \quad\quad \text{for $|q|<1$}.\]

File Transclusion

@mmd

See more at File Transclusion—MultiMarkdown Documentation.

References

Some examples are directly or indirectly copied from the following documentations:

1. Pandoc - Pandoc User’s Guide
2. MultiMarkdown User’s Guide
3. Syntax | kramdown
